Image Sensor |
5 MP CMOS |
Max. Resolution |
2560 (H) × 1944 (V) |
Min. Illumination |
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Time |
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
|
Day & Night |
ICR |
Angle Adjustment |
Pan: 0 to 360°, Tilt: 0 to 180°, Rotation 0 to 360° |
Signal System |
PAL/NTSC |
Lens |
Lens Type |
3.6 mm, 6 mm, 8 mm, 12 mm fixed lens |
Focal Length & FOV |
3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV:105°
6 mm, horizontal FOV: 57°, vertical FOV: 43°, diagonal FOV:72°
8 mm, horizontal FOV: 41°, vertical FOV: 31°, diagonal FOV:52°
12 mm, horizontal FOV: 26°, vertical FOV: 19°, diagonal FOV:32°
|
Lens Mount |
M12 |
Image |
Image Parameters Switch |
STD/HIGH-SAT |
Image Settings |
Brightness, Sharpness, Mirror, Smart IR |
Frame Rate |
TVI: 5M@20fps, 4M@30fps, 4M@25fps, 1080p@30fps, 1080p@25fps
AHD: 5M@20fps, 4M@30fps, 4M@25fps
CVI: 4M@30fps, 4M@25fps
CVBS: PAL/NTSC
|
Day/Night Mode |
Auto/Color/BW (Black and White) |
Wide Dynamic Range (WDR) |
Digital WDR |
Image Enhancement |
DWDR/BLC/HLC/Global |
Noise Reduction |
Yes |
White Balance |
Auto/Manual |
AGC |
Yes |
Interface |
Video Output |
Switchable TVI/AHD/CVI/CVBS |
General |
Material |
Front Cover: Metal
Main Body: Plastic
|
Dimension |
78.9 mm × 75.4 mm × 216.6 mm (3.10″ × 2.97″ × 8.53″) |
Weight |
Approx. 330 g (0.73 lb.) |
Operating Condition |
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
Communication |
HIKVISION-C |
Language |
English |
Power Supply |
12 VDC ± 25% |
Consumption |
Max. 5 W |
