Hikvision DS-7204HQHI-K1 4-ch 1080p 1U H.265 PoC DVR

Original price was: ৳ 7,800.00.Current price is: ৳ 6,290.00.

  • Faster Fingerprint
  • Dust & Water Proof
  • Communicates phones
  • Dual, Multi-Smartcard
+
  ... people are viewing this right now
Compare
  • Recording
  • Video compressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
  • Encoding resolution

    When 1080p lite mode is not enabled:

    4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF

    When 1080p Lite mode is enabled:

    4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF

  • Frame rate

    Main stream:

    When 1080p Lite mode not enabled:

    For 4 MP stream access:

    4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

    For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps

    For 1080p stream access:

    1080p/720p @15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

    For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

    When 1080p Lite mode enabled:

    4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

    Sub-stream:

    WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)

  • Video bit rate32 Kbps to 6 Mbps
  • Dual streamSupport
  • Stream typeVideo, Video & Audio
  • Audio compressionG.711u
  • Audio bit rate64 Kbps
  • Video and Audio
  • IP video input2-ch (up to 6-ch) Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
  • Analog video input4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
  • AHD input4 MP, 1080p25, 1080p30, 720p25, 720p30
  • HDCVI input1080p25, 1080p30, 720p25, 720p30
  • CVBS inputPAL/NTSC
  • Audio input1-ch, RCA (2.0 Vp-p, 1 KΩ)
  • Audio output1-ch, RCA (Linear, 1 KΩ)
  • Two-way audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
  • Synchronous playback4-ch
  • HDTVI input

    4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25

    *: The 3 MP signal input is only available for channel 1 of DS-7204HQHI-K1/P, channel 1/2 of DS-7208HQHI-K2/P, and channel 1/2/3/4 of DS-7216HQHI-K2/P.

  • VGA/HDMI output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
  • PoC camera inputSupport Hikvision PoC camera *: PoC access capability see Appendix.
  • CVBS output1-ch, BNC (1.0 Vp-p, 75 Ω),resolution: PAL: 704 × 576, NTSC: 704 × 480
  • Network
  • Remote connections32
  • Network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
  • Network interface1, RJ45 10M/100M self-adaptive Ethernet interface
  • Auxiliary interface
  • SATA1 SATA interface
  • CapacityUp to 10 TB capacity for each disk
  • Alarm in/outN/A
  • USB interface2 × USB 2.0
  • Serial interfaceRS-485 (half-duplex)
  • General
  • Power supply48 VDC
  • Working temperature-10 °C to +55 °C (+14 °F to +131 °F)
  • Working humidity10% to 90%
  • Dimensions (W × D × H)315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)
  • Weights (without HDD)≤ 1.16 kg (2.6 lb)
  • Consumption (without HDD)≤ 40 W
